UVC RO Water Purifier

(0 reviews)

Get Price

(61) Views

(0) Contacts

Contact Company

Shenzhen Hechuang Hitech CO., LTD.

Shenzhen, China

(286) Views

(0) Contacts

99.999% disinfection rate

The filtration precision is 0.0001m, and the wastewater ratio is low, allowing for a higher drinking water demand.
The filter core with a flat interface is simple to install.
The sterilizing module has a long service life and is inexpensive.

                                                            Module NO.
                                                            HC-JS-600B

                                                            Sterilization Mode
                                                            UVC-LED

                                                            Sterilization Module
                                                            70mW, SS304

                                                            Filtration System
                                                            CSM RO-600G , Flat composite filter core, flat rear carbon filter core

                                                            Power
                                                            Input: 100~240VAC  Output: 24VDC 3.0A

                                                            Water Source
                                                            Municipal Water

                                                            Solenoid Valve Washing
                                                            24VDC 200mA 420 Insert Fin

                                                            Working Pressure
                                                            0.4--0.7MPa

                                                            Solenoid Valve Water Inlet
                                                            24VDC 200mA 420 Insert Fin

                                                            Adaptable Ambient Temperature
                                                            4--38℃

                                                            High Pressure Switch
                                                            Quick Connect Interface 1/4O.D. 187 Insert Fin

                                                            Adaptable Water Temperature
                                                            5--38℃

                                                            Booster Pump
                                                            Booster Pump (24V/2.5A) L6.2-2Y

                                                            Relative Humidity
                                                            No more than 90%(25℃)

                                                            Touch Spring
                                                            Dia. 0.5mm; ￠11 Height 15~17mm

                                                            Residual Chlorine(PPM)
                                                            < 0.01

                                                            Display Panel (with TDS water quality display)
                                                            80*46*1.2mm XHB-8PIN

                                                            Water Hammer Test
                                                            No water leakage with repeating 100000 times  Under the working pressure of 0 ~ 1.04MPa

                                                            Low Pressure Switch
                                                            Null

                                                            TDS Value(PPM)
                                                            The ratio of raw water to purified water is about 100：5 (for reference)

                                                            Rated Total Purified Water Volume
                                                            3m³

                                                            Desalination Rate
                                                            More than 96%

                                                            Purified Water Volume
                                                            1.5L/min

                                                            Sterilization Rate
                                                            99.999%

                                                            PH Value
                                                            No less than 8.0

                                                            Size
                                                            465*161*460mm

                                                            Machine Pressure Resistance  (excluding pressure barrel)
                                                            1.2MPa

                                                            Burst Pressure
                                                            ≥2.76MPa or 4 times of the highest working pressure

Functions of RO Water Purifier include:

The built-in UVC-LED Sterilization Module of the Reverse Osmosis Water Purifier disinfects drinking water. Ultraviolet disinfection employs high-intensity short-wavelength (250-280nm) light to inactivate germs by damaging nucleic acid and DNA, rendering them incapable of playing a key role in cell function. As a result, ultraviolet has become one of the most rapidly expanding disinfection technologies.(Cocci, Bacilli, Vibrio, Spirillum, and other organisms are eliminated.)

Specifications of RO Water Purifier:

The reverse osmosis water purifier comprises a three-stage filtration system that includes a scale inhibition composite filter core, a RO membrane, and a post carbon filter core. Furthermore, the UVC sterilization module ensures the safety of drinking water and solves the problem of surplus bacteria with a lengthy carbon filtering time.
