Telecom DC Hybrid Solar 6U Power System 48V 400A 600A Solar Module 4000W IBAN EPS 48400

(0 reviews)

Get Price

(952) Views

(0) Contacts

8-slot bay, freely hot-swappable solar modules and rectifier modules, highly configurable.

Contact Company

I-BAN International Corp.

New Taipei, Taiwan

(3466) Views

(14) Contacts

                                                            Output Type
                                                            Single

                                                            Output Frequency
                                                            47~63Hz

                                                            Output Voltage
                                                            53.5Vdc (42~58V)

                                                            Max Output Current
                                                            600A

                                                            Overvoltage Protection
                                                            59Vdc

                                                            Frame Slots
                                                            8pcs (full accessories)

                                                            Working Temperature
                                                            -40~55°C

                                                            Rectifier Module
                                                            3000W, 4000W

                                                            Solar Module
                                                            4000W

                                                            Warranty
                                                            5 years

                                                            Application
                                                            Telecom

Applications of Telecom DC Hybrid Solar 6U Power System:
1.Solar power supply
During the day, the system utilizes solar energy to power the load, while at night, it relies on battery power to enhance system efficiency
2.Peak cut
The system charges the batteries from the grid during off peak hours, and when there is no solar energy available during peak grid demand times,
the batteries power to the load
3.Backup power
When the grid is interrupted, the system uses the batteries to provide power to the load, serving as a backup power source

Features of Hybrid Solar 6U Power System

1.Energy saving efficiency
Reducing energy losses from the traditional solar inverters repeated conversions to enhance energy efficiency
2.Equipment efficiency
Integrated into a single device, it reduces equipment expenses, installation and maintenance costs, minimizes wire wastage, maximizes space utilization, and lowers the risk of failures
3.Network integration
Conserving network management IP resources, with a single interface for communication and protocols, facilitating integration and maintenance of energy management systems
