Smart Sludge Dewater Screw Press

(0 reviews)

Get Price

(26) Views

(0) Contacts

Contact Company

Hangzhou NIHAO Environmental Tech Co., Ltd.

Zhejiang, China

(116) Views

(0) Contacts

Minimal vibration, minimal noise, energy and water conservation.
The screw, which serves as the primary component, rotates slowly at a pace of 2-4 rpm. Because it doesn't require huge integration like rollers, it uses relatively little power and is hence environmentally beneficial. The screw press uses 1/8 of the power of a belt press, which uses only 0.01-0.1 Kwh/kg-DS, and 1/20 of that of a centrifuge, which needs to rotate at a high speed.Because of its special self-cleaning mechanism, clogging of the filter mesh is avoided without requiring a lot of water.
The control cabinet has the ability to operate the machine automatically as well.
Broad range of uses. Widely used in the oil and chemical industry, paper production, leather goods, food processing, breeding, slaughtering, printing, dyeing, and other industrial sludge dewatering processes.
NIHAO Water-Serviceable Screw Press Range
A variety of types of specially built screw presses are available, with capacities ranging from 0.5 kg-DS/h to 1320–1768 kg-DS/h. It is capable of handling many types of waste water, such as activated sludge, chemical precipitated sludge, raw sludge, and DAf sludge. In accordance with the actual requirement, we can also offer the best technical proposal.
DRAWINGS ARE GOT BY CREW STANDARD CONFIGURATION AND STRUCTURE
The Standard Configuration of NIHAO SCREW
Tank for Flow Control The sludge pump feeds the sludge into the Flow Control Tank, where it is regulated by the overflow pipe and the excess volume is returned to the sludge storage tank.
One Flocculation Tank A appropriate "floc" is formed by stirring and mixing the sludge with the polymer.
Two Cylinders for Dewatering The cylinder's thickening zone thickens the conditioned sludge, and the dewatering zone's higher inner pressure aids in the sludge's thorough dewatering.
Sludge Cake Discharge Outlet No. 3 More pressure is applied from the end plate's output side, causing the sludge cake with a solids content of more than 20 percent to discharge.
Preparation unit for PE polymers
A basic PE dosing equipment is the PE Polymer Preparation equipment.Stirring motor, mixer, dosing port, water inlet, and washing water inlet make up the unit.
It is inexpensive and suitable for small-scale, on-site projects involving workers.
PREPARE AUTOMATIC POLYMER UNIT
Powder polymer preparation is done with an automatic polymer preparation unit.created with flocculant concentration uniformity in mind. A design that is optimized can guarantee that the polymer matures with the least amount of environmental impact.

Benefits of SMART SLUDGE DEWATER SCREW PRESS

PMMA Windows and a Steel Cover Make It Safer
The equipment is safer and workers are safer when operating the stainless steel cover, which has two handles on top of the main boiler and strengthened polymethyl methacrylate glass windows in both sizes. Additionally, the worker can carefully inspect the machine while it is using Windows.
Assure Longer Life of the Steel Sprinkler System
All of the components of the Juntai Screw Press sprinkler system, including the pipe, inject, and nozzel, are constructed of SS304, so the sprinkler nozzel will never need to be replaced. The sprinkler system is crucial to the dewatering system and is the easiest to use.
Extended Life Characterizing Guaranteed QualitEvery feature of the Screw Press, including the smooth surface, the cable protection, the wire stability, the radius and smooth angles, the welded line, and all other details, is the focus of Nihao's attention. By doing this, we also ensure the quality.
Emphasizing the Cobalt Alloy Wear Layer Details Harden Screws
The Nihao Dewatering Machine's screws are all welded with a cabalt alloy wear layer, which is far harder than SS304. Because of this wear layer, the screw is stronger and has a longer lifespan.
Stronger Screw
Schneider Electric Control Cabinet made in Germany
The German Schneider Electric control box, which is put on the Nihao dewatering machine, is of superior quality and can better ensure safety. Schneider Germany
Cleaning is Made Easier with a Pressure Water Gun and Fiberglass Hose.
The Nihao Dewatering Machine's screws are all welded with a cabalt alloy wear layer, which is far harder than SS304. Because of this wear layer, the screw is stronger and has a longer lifespan.
Cleaner Easily
Benefits of LUDGE DEWATER SCEW PRESS 6 technology

Possessing a pre-thickening tank and being more adept at handling sludge with low concentration.
Corrected the inefficiencies in gravity thickening and achieved highly effective thickening.When thickening and flocculation are combined, dewatering is made simpler.Optimizing sludge concentration is possible when combined with a controlling end plate.
Filter cloth is replaced by moving and fixed rings.
The screw shaft's rotation forces the Moving rings to separate from the Fixed rings, initiating an automatic and continual self-cleaning operation.
This makes it possible to conduct steady, continuous dewatering without relying on high-pressure water flushing to avoid blockages.
This makes it perfect for oily sludge as well, which clogs easily and is challenging to deal with using conventional dewatering tools.
