For investors and project planners, the SolarMaster solar panels offer the highest levels of energy density and dependability. At a fantastic price, SolarMaster Mono & Poly solar panels offer effective performance and long-lasting sturdiness. It converts the highest percentage of sunlight into power when compared to other technologies. This implies that you will produce more electricity and reduce your electricity costs over the course of the system's lifetime.

                                                            Cell Type
                                                            182*91mm, Mono, 144pcs in series

                                                            Demensions
                                                            2279*1134*35mm

                                                            Weight
                                                            27KGS

                                                            Front Cover
                                                            3.2mm Tempered glass

                                                            Frame
                                                            Anodized Aluminum Alloy

                                                            Junction Box
                                                            IP67/IP68

                                                            Rated Cable
                                                            4mm2(EU) / 12AWG(US), 1200mm

Characteristics of Solar PV Panels

High Conversion Efficiency: Thanks to advancements in cell technology and manufacturing capabilities, modules have an efficiency of up to 21.32%.
Outstanding Weak Light Performance: Outstanding results in dim light.
Positive Tolerance: Higher output reliability is achieved with a positive tolerance of up to 0–3 W.
Present Sorting Procedure: Modules are sorted and packaged based on amperage to minimize mismatch losses and maximize system output.
Extended Wind & Snow Load Tests: 3800 Pascal of strong wind and 5400 Pascal of snow load are verified for the module.
Managing a Severe Environment: Better sustainability is a result of dependable quality, even in arid, agricultural, and coastal environments.
