Demineralise Mix Bed

(0 reviews)

Get Price

(315) Views

(0) Contacts

Contact Company

AQUILA RO SYSTEM PVT LTD

Gujarat, India

(1056) Views

(0) Contacts

Higher-quality, more reasonably priced demineralise water is constantly in demand by the industry. The dissolved contaminants, such as various mineral salts and compounds of Ca, Mg, Na, K, and Fe carrying positive ions and So4, Cl, Co3, Hco3, and Sio2, etc. carrying negative ions, as well as organic and inorganic impurities, make naturally occurring water scarcely suitable for industrial demands. Natural water sources cannot meet the better quality (dissolved salt-free) water requirements of industry for specific process formulations and the use of the newest, most expensive equipment.
Principle of Demineralise Mix Bed:
Demineralization of Aquila The most recent coast-effective ion exchange method of countercurrent regeneration is used in the design of plants. The units are made up of two internal, series-connected, corrosion-free pressure vessels. An anion-absorbing exchanger is charged in the second column, while a cation-absorbing exchanger is present in the first. Water passes through an anion exchanger's bed after passing through a cation exchanger's bed. As a result, the systems eliminate dissolved salts from water to a certain extent.
Cation and anion regeneration must be performed following the utilization of the systems' whole exchange capability. An alkali solution is used to rejuvenate the anion exchange resin, whereas an acid is used to revive the cation exchanger. AQUILA demineralizers include a set of regeneration equipment, hydraulic ejectors, acid and alkali tanks, a conductivity meter to check the quality of the treated water, an acid/alkali-proof pressure vessel with internal fittings, and an initial charge of a cation and anion exchanger. These demineralizers provide the useful range of capacities and flow rates required to meet the needs of several applications.

DESIGN:

Based on feed water analytical parameters and customer end parameters.
The system is designed to satisfy the water quality requirement.
We create systems that are simple to use and maintain.
Using a range of technologies, we provide sustainable design services.
For a cost-effective solution, we are using a variety of pumps and membrane types and their manufacturers.
To achieve the necessary parameters, we are using precise pre- and after RO treatment.
SUCCESSFUL O&M, PRECISE DESIGN, AND DEEP ANALYSIS.
We believe in the idea of success by design. This implies that recurring success cannot happen by accident or chance. Rather, it needs to be planned and crafted.
We have fulfilled our commitment to the client by achieving 100% results.In the design of waste water and clean water.

                                                            Flow
                                                            0.2M3/hr to 100M3/hr

                                                            Operational Valve
                                                            Auto/Manual

                                                            Inlet TDS
                                                            UP TO 800 ppm

                                                            Outlet TDS
                                                            <10-20 PPM

                                                            Type of Resin
                                                            Strong Acid Cation (H+ – Mono Type) : Strong Base Anion (OH+ – Mono Type)

                                                            OBR
                                                            UP TO 2200 M3

                                                            Type of Regenerant
                                                            HCL / H2SO4 for SAC & NaOH for SBA.

                                                            Diameter (Vertical Vessel)
                                                            0.225 Mts. – 4.0 Mts.

                                                            Control
                                                            Microprocessor / Hmi display with PLC / Scada

                                                            Design Pressure
                                                            Up to 10 Bar

                                                            Working Pressure
                                                            1.1 to 3.5 Bar

                                                            Coating / lining
                                                            Epoxy / FRP / Rubber Lined

                                                            Design Code
                                                            ASME/IS

                                                            MOC
                                                            FRP / Mid Steel / Stainless Steel

                                                            Distribution System
                                                            FRP/Strainer Plate

                                                            Brine Mixing Element
                                                            Agitator

                                                            Operation Type
                                                            MPV/Frontal Piping

                                                            Feed Pump
                                                            C.I/SS304/SS316

                                                            Flow Measurement
                                                            Rotameter/Flow Meter

                                                            Pressure Measurement
                                                            Pressure Guage/Diffrential Pressure Transmiter

Private Characteristics of Water Softening Plant

Personalize programmable controllers to your specifications.
Use each component only with its test certificate.
The engineered plant is plug-and-play for easy installation.
Built-in clean-in-place attachments to make maintenance simple.
Employ the least amount of footprint without sacrificing o&m space.
Provide the components data sheet, test certificates, daily operation and maintenance logsheet, and user manual for every project.
Systems for rapid approval that maintain project momentum.
Installation is simple, and operation and maintenance are accurate.
Produces excellent neutral water.
Variety of basic components that are affordable.
