Our solar panels provide a stable source of energy by capturing the power of the sun, decreasing your dependency on traditional energy sources and potentially saving you money on your energy bills. With our Photovoltaic Solar Panels, you can invest in a more sustainable future for your home and the globe.
Cell Perc
The PERC cell has a passivated rear side and a laser grooving process, which boosts cell efficiency dramatically. Solar panels, also known as photovoltaics (PV), absorb the sun's energy and convert it into electricity for use in your home. You can generate your own renewable electricity by installing solar panels.
How Do Solar Panels Function?
Photovoltaic solar panels are made up of numerous cells comprised of semi-conducting materials, most often silicon. When light strikes on this substance, an electric current flows. The cells do not require direct sunlight to function and can even function on cloudy days. However, the more sunlight there is, the more power is generated.
Solar PV systems are made up of multiple panels, each of which generates approximately 355W of energy in direct sunlight. Typical setups have 10 panels and produce direct current (DC) electricity. Because household equipment need alternating current (AC), an inverter is integrated with the system to convert DC electricity to AC. This energy can be consumed in your home or sent to the grid.
Technology Based on Half Cells
Use Current And Loose
The current density is lowered by half, the internal power loss is reduced by a quarter, and the rated output power is enhanced.
Shading Loss Is Minimal
The split-type module design efficiently lowers the current mismatch mismatch induced by shadow, resulting in increased power output.
Working Temperature is Low
The operating temperature of half-cell modules is 2-3°C lower than that of full-cell modules, ensuring a more secure working environment.

                                                            Max System Voltage
                                                            DC 1500/1000(1 EC)

                                                            Weight
                                                            19.5kgs

                                                            Max Series Fuse Rating
                                                            20A

                                                            Frame
                                                            Anodized aluminum alloy frame

                                                            Operating Temperature
                                                            -40 C to + 85 C

                                                            Standard Test Condition(STC)
                                                            Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5

                                                            Cell Orientation
                                                            120 (6x20)

                                                            Junction Box
                                                            IP68, three diodes

                                                            Output Cable
                                                            4mm2, 300mm in length, length can be customized

                                                            Glass
                                                            Single glass 3.2mm coated tempered glass
