Ultrafiltration is a membrane separation method capable of purifying and separating solutions.The ultrafiltration membrane system is a solution separation device that uses ultrafiltration membrane silk as the filter medium and the pressure difference between the membrane's two sides as the driving force.It only allows the solvent (such as water molecules), inorganic salts, and small molecular organic substances in the solution to pass through, while retaining the macromolecular substances in the solution such as suspended solids,colloids,proteins, and microorganisms.
The operating principle of Ultrafiltration Equipment
Ultrafiltration is a membrane separation method that uses sieving as the separation mechanism and pressure as the driving force.The filtration precision ranges from 0.005-0.01um, allowing it to successfully remove particles,colloids,bacteria,heat sources, and macromolecular organic compounds from water.It has a wide range of applications in the separation, concentration, and purification of chemicals.In the ultrafiltration process, there is no phase inversion.It works at room temperature and is ideal for the separation of heat-sensitive compounds.It is resistant to high temperatures, acids and alkalis, and oxidation.It can operate continuously for a long time at temperatures below 60 °C and pH levels ranging from 2 to 11.

Filter media suspended matter, colloids, proteins and microorganisms in solution.

Applications of Ultrafiltration Equipment

Reverse osmosis pretreatment
Drinking water treatment
Reclaimed water reuse
Other applications.

Benefits of Ultrafiltration Equipment

Design that is stable and personalized:

Low energy usage and a short manufacturing cycle.Its running expenses are reduced as compared to typical process equipment, and it can effectively cut production costs.

High rate of recovery:

When paired with powerful control software, personalized design can be carried out based on the individual needs of consumers.

Structure

Structure is compact:

The system has an innovative process design, a high degree of integration, a compact structure, a small footprint, is simple to operate and maintain, and requires little labor.
Centralized online monitoring of critical process operation parameters to eliminate human errors and reduce labor expenditures.

Stable

Design customization:

Because the ultrafiltration process just employs pressure to separate membranes, the separation device is simple, the process is brief, the operation is simple, and it is simple to operate and maintain.
Ultrafiltration technology has a high separation efficiency, making it ideal for recovering trace components in dilute solutions and concentrating them.

Handy and simple to use:

Reasonable design, good purifying effect, suited for a variety of environments.
The personalized design in accordance with the local water quality can meet the needs in a comprehensive manner. The equipment is compact and takes little room.
