UVC RO Water Boiler

(0 reviews)

Get Price

(66) Views

(0) Contacts

Contact Company

Shenzhen Hechuang Hitech CO., LTD.

Shenzhen, China

(287) Views

(0) Contacts

99.999% disinfection rate

The increased flow rate can match the increased demand for drinking water.
The snap-type filter core is simple to install.
The sterilizing module has a long service life and is inexpensive.

                                                            Module No.
                                                            HC-SWRO-10L

                                                            Sterilization Mode
                                                            UVC-LED

                                                            Sterilization Module
                                                            70mW*2, SS304

                                                            Filtration System
                                                            RO100G(Optional pressure bucket, plastic pressure:3.2g）CSM RO-75G, Integrated Composite Filter Core, Integrated Rear Carbon Filter Core

                                                            Power
                                                            Input: 100~240VAC

                                                            Water Source
                                                            Municipal Water

                                                            Cover Material
                                                            Stainless steel with black brushing process

                                                            Heating Power
                                                            1000W

                                                            Working Pressure
                                                            0.4--0.7MPa

                                                            Adaptable Ambient Temperature
                                                            4--38℃

                                                            Heating liner material
                                                            Food Grade 304 stainless steel

                                                            Burst Pressure
                                                            ≥2.76MPa or 4 times of the highest working pressure

                                                            Adaptable Water Temperature
                                                            5--38℃

                                                            Heating Method
                                                            Walking Type of Heating technology

                                                            Residual Chlorine(PPM)
                                                            < 0.01

                                                            Relative Humidity
                                                            No more than 90%(25℃)

                                                            Display Panel
                                                            140*80*1.6mm DQ-4A001

                                                            Water Hammer Test
                                                            No water leakage with repeating 100000 times Under the working pressure of 0 ~ 1.04MPa

                                                            Withstand Voltage of RO Machine
                                                            1.2MPa

                                                            Direct Drinking Water Storage
                                                            Direct Drinking Water 15L

                                                            Size
                                                            1400*380*350mm

                                                            PH Value
                                                            No less than 8.0

                                                            TDS Value(PPM)
                                                            The ratio of raw water to purified water is about 100：5 (for reference)

                                                            Sterilization Rate
                                                            99.999%

                                                            RO Machine Water Making Volume
                                                            260mL/min

                                                            Boiled Water Storage
                                                            Boiled water 7L

                                                            Desalination Rate
                                                            More than 96%

Applications of UVC RO Water Boiler

Offices, factories, schools, hospitals etc.
The Commercial RO Water Boiler's built-in UVC-LED Sterilization Module disinfects drinking water. Ultraviolet disinfection employs powerful short wavelength (250-280nm) light to inactivate germs by damaging nucleic acid and DNA, rendering them unable to play a key part in cell function. As a result, ultraviolet has emerged as one of the most rapidly increasing disinfection technologies.(Cocci, Bacilli, Vibrio, Spirillum, and other organisms are excluded.)

Specifications of UVC RO Water Boiler:
The Commercial RO Water Boiler has its own triple filtration system: composite filter core + RO membrane + post carbon filter core. Furthermore, the UVC sterilization module ensures the safety of drinking water and solves the problem of excessive bacteria with a long carbon filtering time.
