Ultrafiltration Membrane Module For Water Treatment X-HFU-2020N
(0 reviews)
Get Price
(7) Views
(0) Contacts

PVDF, or polyvinylidene fluoride, is the most sophisticated hollow fiber membrane material with great mechanical strength and chemical stability. It is used to make hollow fiber (HF) pressure ultrafiltration (UF) membrane modules.


Contact Company





X Membrane
Jiangsu, China
(86) Views
(0) Contacts

X Hollow-fiber Membrane Module Specifications
Module Part Number
HFU-2020
HFS-2020
Nominal pore size | µm
0.01
Outer Membrane Surface Area | m2 (ft2)
72 (775)
72 (775)
Maximum Feed Water Flow | m3/h (gpm)
15 (66)
12 (53)
Maximum Backwash Flow | m3/h (gpm)
16.8 (74)
13.5 (59)
Maximum Air Flow | Nm3/h (scfm)
9 (5.3)
9 (5.3)
Filtration Method
Pressure type / Outside to inside / Dead-end
Dimensions
Diameter | mm (in)
216 (8.5)

Length | mm (ft)
2,160 (7.087)
Weight
kg (lbs)
Full of water
110kg

After draining
67kg
Materials

Membrane
PVDF (Polyvinylidene fluoride)

Casing / Protective Cylinder

PVC (Polyvinychloride)

Potting

Epoxy resin or equivalent

Maximum water inlet pressure 300KPa (44psi)
Maximum differential pressure across membrane 2000KPa (29psi)
Operating temperature range 0-40℃
PH range filtration 1-10; chemical cleaning 0-12
Nominal aperture 0.01mm
Design flux 8.0-2.6 cubic meters per hour
Maximum feed temperature 40 degress C
Maximum feed pressure 300kpa
Feed pH Range Operation 1-10
Nominal MWCO 150,000large
Feed pH range clean 0-12
Weight full of water 110kg
Feed pH range clean 216mm
Cap & Nut (housing) Integrated
Connection Bottom Housing joints 80A
Connection Side Housing joints 65A
Connection Top Housing joints 80A
Maximum inlet pressure | kPa (psi) 300 (44)
pH range During cleaning 0–12
Maximum backwash pressure | kPa (psi) 300 (44)
pH range During filtration 1–10
Normal operating trans-membrane pressure | kPa (psi) 0–200 (0–29)
Operating temperature range | °C (°F) 0–40 °C (32–104 °F)

Applications of Ultrafiltration Membrane Module include

  1. Seawater desalination (for RO pretreatment)
  2. Industrial water treatment
  3. Generation of drinking water.

Benefits of Ultrafiltration Membrane Module
  1. Modules of X PVDF hollow fiber membrane are used in many kinds of water treatment and are useful for efficiently eliminating microorganisms including germs and suspended particles.
  2. PVDF, or polyvinylidene fluoride, is the most sophisticated hollow fiber membrane material with great mechanical strength and chemical stability.
  3. It is used to make hollow fiber (HF) pressure ultrafiltration (UF) membrane modules.
  4. The complete volume filtering method and external pressure type are the filtering modes.
  5. Ultrafiltration membranes benefit from this filtration mode's low energy consumption and ease of use.
