UFc200BL PVC Hollow Fiber Ultrafiltration Membrane

(0 reviews)

Get Price

(151) Views

(0) Contacts

Contact Company

Zhuhai Bangmo Technology Co., Ltd

Guangdong, China

(448) Views

(1) Contacts

PVC series pressurized UF membrane modules use imported PVC raw material with long service life, and filtering precision is 0.01 microns. Due to its high rigidity, PVC can be made into thicker hollow fibers and bear high working pressure, which is applicable to inside-out working mode. The Inside-out structure is applicable for raw water with low turbidity and SS. When inside-out membrane modules work, contaminants are rejected inside hollow fibers without dead angles, which are easy to be washed out.

                                                            Model
                                                            UFc200BL

                                                            CIP
                                                            When it comes to Maximum TMP

                                                            Filter Type
                                                            Inside-out

                                                            Backwashing Frequency
                                                            30~60min

                                                            Pore Size
                                                            0.01μm

                                                            CEB
                                                            1~4 (Times/day)

                                                            Membrane Area, m2
                                                            34

                                                            Size, mm
                                                            ø200 x1710

                                                            SDI15 / Ultrafiltrate SDI15
                                                            ≤3

                                                            Backwashing Pressure
                                                            ≤0.2MPa

                                                            Connector Size, mm
                                                            Ø50

                                                            Shell Material
                                                            UPVC

                                                            Sealing Material
                                                            Epoxy Resin+PU

                                                            Ultrafiltrate Turbidity
                                                            ≤0.1NTU

                                                            TMP
                                                            ≤0.2MPa

                                                            Operating Flux
                                                            35~100L/m .h

                                                            Backwashing Flux
                                                            100~150L/m .h

                                                            Operating Pressure
                                                            ≤0.3MPa

                                                            Turbidity
                                                            ≤15NTU

                                                            PH
                                                            5~9 ( Washing2~12)

                                                            Temperature
                                                            5~45℃

Applications of PVC Hollow Fiber Ultrafiltration Membrane

Treatment of surface water & groundwater
Municipal drinking water treatment
Reuse of industrial wastewater
RO
RO pretreatment

Features of PVC Hollow Fiber Ultrafiltration Membrane

SS≤1mg/L、 ≤0.1NTU、SDI≤3
Ultrafiltrate SS≤1mg/L, turbidity≤0.1NTU, SDI≤3
High porosity, evenly distributed
The low breaking rate of hollow fibers ensures the stable quality of ultrafiltrate
3~5 years service life under normal use
