The hardness-producing ions, calcium, and magnesium in varying concentrations are the most and least acceptable chemical contaminants in water. Additionally, they are in charge of the hard scale that accumulates in the circulating system, condenser jackets, boiler tubes, pipe lines, cooking utensils, and other hot water-contracted equipment.
The main purpose of AQUILA Softener is to create zero soft water by removing calcium and magnesium ions using a very acidic cation exchanger. Which substances in the water cause dissolved hardness and are substituted by sodium ions?
Co-current regeneration with a downflow rate and countercurrent regeneration with an upflow rate are features of the AQUILA line of water softeners. Longer running cycles and reduced regeneration costs are features of the AQUILA series softeners. The systems use the tried-and-true method of counter and co-counter currant regeneration flow rate to cheaply meet the soft water needs of commercial and medium-sized companies.
The principle of water softening
A sodium-based high-capacity polystyrene bead cation exchange resin powers the water softeners. The hardness-forming calcium and magnesium salts are swapped out for sodium salts, which have no hardness qualities, when hard water flows through this resin column. When the material is regenerated using a solution of regular salt, the softening process continues until the sodium salts have been used up. Consistently high-quality treated water is guaranteed by the water softener units' sophisticated co-current/counter-current architecture.
DESIGN:

Based on feed water analytical parameters and customer end parameters.
The system is designed to satisfy the water quality requirement.
We create systems that are simple to use and maintain.
Using a range of technologies, we provide sustainable design services.
For a cost-effective solution, we are using a variety of pumps and membrane types and their manufacturers.
To achieve the necessary parameters, we are using precise pre- and after RO treatment.
SUCCESSFUL O&M, PRECISE DESIGN, AND DEEP ANALYSIS.
We believe in the idea of success by design. This implies that recurring success cannot happen by accident or chance. Rather, it needs to be planned and crafted.
We have fulfilled our commitment to the client by achieving 100% results.In the design of waste water and clean water.

                                                            Flow
                                                            0.5 M3/hr to 100 M3/hr

                                                            OBR
                                                            2200 m3

                                                            Inlet Hardness
                                                            Up to 600 Mg/L

                                                            Outlet Hardness
                                                            <5 mg/L (Commercial ZERO)

                                                            Linear Velocity
                                                            4 to 30 M/Hr

                                                            Space Velocity
                                                            4 to 20 M/Hr

                                                            Type of Resin
                                                            Strong Acid Cation (Na+ – Mono Type)

                                                            Type of Regenerant
                                                            NaCl

                                                            Diameter (Vertical Vessel)
                                                            0.225 Mts. – 4.0 Mts.

                                                            MOC
                                                            FRP / Mid Steel / Stainless Steel Coating / lining : Epoxy / FRP / Rubber Lined

                                                            Design Code
                                                            ASME / IS

                                                            Design Pressure
                                                            Up to 10 Bar

                                                            Working Pressure
                                                            1.1 to 3.5 Bar

                                                            Clear Pressure Drop
                                                            0.3 bar

                                                            Distribution system
                                                            FRP/Strainer Plate

Water Softening Plant applications

Boiler and cooling water feed applications. Process water for textiles and chemicals. Homes, hospitals, hostels, ice plants, and commercial and institutional water power plants.

Private Characteristics of Water Softening Plant

Personalize programmable controllers to your specifications.
Use each component only with its test certificate.
The engineered plant is plug-and-play for easy installation.
Built-in clean-in-place attachments to make maintenance simple.
Employ the least amount of footprint without sacrificing o&m space.
Provide the components data sheet, test certificates, daily operation and maintenance logsheet, and user manual for every project.
Systems for rapid approval that maintain project momentum.
Installation is simple, and operation and maintenance are accurate.
Produces excellent neutral water.
Variety of basic components that are affordable.
