Peristaltic Metering Pump

(0 reviews)

Get Price

(246) Views

(0) Contacts

Contact Company

Blue-White Industries

California, USA

(781) Views

(0) Contacts

Included:

M1 Peristaltic Pump for Metering
Two assembly of tubes
Hardware kit for mounting
shield for displays

                                                            Maximum Working Pressure
                                                            (Excluding pump tubes) 100 PSI (6.89 bar)

                                                            Standards
                                                            NSF/ANSI 61, cETLus, CE

                                                            RoHS Compliant
                                                            Yes

                                                            Maximum Fluid Temperature
                                                            185 °F (85 °C)

                                                            Maximum Viscosity
                                                            5,000 centipoise

                                                            Maximum Suction Lift
                                                            30 ft. of water at sea level (14.7 atm psi)

                                                            Ambient Operating Temperature
                                                            14 °F to 115 °F (-10 °C to 46 °C)

                                                            Ambient Storage Temperature
                                                            -40 °F to 158 °F (-40 °C to 70 °C)

                                                            Operating Voltage
                                                            115V60Hz 1 PH (0.6A max.) 220V50Hz 1 PH (0.3A max.) 230V60Hz 1 PH (0.3A max.) 230V50Hz 1 PH (0.3A max.) 240V50Hz 1 PH (0.3A max.)

                                                            Power Cord Options
                                                            115V60Hz = NEMA 5/15 (USA) 230V60Hz = NEMA 6/15 (USA) 220V50Hz = CEE 7/VII (EU) 240V50Hz = AS 3112 (Australia/New Zealand) 230V50Hz = BS 1363/A (UK)

                                                            Motor
                                                            Brushless DC, 50W.

                                                            Duty Cycle
                                                            Continuous

                                                            Motor Speed Adjustment Range
                                                            10,000:1 (0.01% – 100%) Max rpm = 65rpm

                                                            Maximum Overall Dimensions
                                                            7.25” W x 9” H x 10” D (18.5 W x 22.9 H x 25.2 D cm)

                                                            Weight
                                                            6 lb. (2.7 Kg)

                                                            Approximate Shipping Weight
                                                            13 lb. (5.9 Kg)

                                                            Approximate Shipping Dimensions
                                                            10.5” W x 13.75” H x 11” D (26.7 W x 35 H x 28 D cm)

                                                            Enclosure
                                                            NEMA 4X (IP66), Valox® (PBT) Thermoplastic & PA12

Characteristics of Peristaltic Metering Pump:
The advantages of a peristaltic pump are the absence of clogged valves that need maintenance.
even when the line pressure is at its highest, self-priming. There's no need for bypass valves.
unable to lose prime or vapor lock.
Skills:
Pressures up to 100 PSI (6.89 Bar) and output rates between.0001 and 5.6 GPH (.0004 and 21.2 LPH) are achievable.
Interface & Communication:
Remote Start/Stop: This feature uses a dry contact closure that is not powered.
There is one solid-state and one 250V/3A relay output.
Flow Verification Sensor (FVS) output from Blue-White is compatible.
SCADA. Inputs and outputs range from 4 to 20 mA.
Exceptionally well-designed and engineered:
Five-Year Warranty
For maximum squeeze, unmatched accuracy, and tube life, use CNC precision-machined squeeze rollers.
A single-piece plastic rotor that is heavy-duty and free of corroding metal springs or hinges results in greater accuracy and no flexing.
brushless DC motor that uses less energy.
specially designed, long-lasting tubing.
Features for Safety:
By identifying compounds in the pump head, Enhanced Tube Failure Detection (TFD+) detects tube rupture. Absence of false triggering Unwanted tampering is prevented by the patented lockout feature. A patent-pending display shield that shields controls from challenging conditions
