Wastewater treatment is the main use for the single-stage centrifugal blower known as the ultra-high-speed turbo blower. During the water treatment process, it rapidly introduces air into the water to aerate it and break down organic debris and microorganisms.
A variable frequency drive (VFD) regulates the speed of a high-speed permanent magnet synchronous motor (PMSM), which drives the blower directly. The revolving shaft is supported by active air bearings, and the impeller is directly attached to the motor. It operates without a gearbox, gas pedal, or linkage.

Parameters

Type		AS-AR20	AS-AR30	AS-AR50	AS-AR60	AS-AR65	AS-AR80	AS-AR90	AS-AR100	AS-AR130	AS-AR150
Shaft Power (KW)		18	27	45	54	65	72	81	90	120	145
Boost(kPa)		Inlet flow rate (m/min), 20°C, 65% humidity, standard atmospheric force
40		18	24	44	47	45	67	70	88	88	129
50		18	23	41	45	44		67	82	82	20
60		17	22	38	43	42	59	64	76	76	111
70		16	21	35	41	40	55			70
80		15	18	32	35	37	49	52	64	64	93
90		12	16	28	31	35	43	46	56	56	81
Outlet Caliber(mm)		DN150			DN200					DN250	DN300
Weight(kg)		400			450					600	680
Size(mm)	Length	1100			260					1780	1800
	Width	900			1000					1300	300
	Height	1200			1220

In terms of wastewater treatment, it offers the following benefits:

High effectiveness and energy conservation
Minimal sound
stable functioning
