Reverse Osmosis Water Treatment Equipment

(0 reviews)

Get Price

(227) Views

(0) Contacts

Cream Lotion Shampoo Reverse Osmosis Water Treatment Equipment Seawater Ionizer Desalination

>= 1 sets
$9,715.00

Contact Company

Guangzhou Qihang Machinery & Equipment Co., Ltd

Guangdong, China

(2217) Views

(7) Contacts

Reverse osmosis, or RO, can be described as a procedure whereby pure water and contaminants are divided via a semi-permeable membrane(s) with very fine pores. This method is a necessary technique employed in the majority of water purification systems. Reverse osmosis is considered to be a highly effective approach to eliminating water impurities, such as cosmetics and radiation, mercury, chlorinated pesticides, organic matters, turbidity & dissolved solids, bacteria, and viruses.

Different Filters for Each Link

1. Quartz Sand filter

The quartz sand filter (multi-media filter) is widely used in drinking water treatment to remove different types of particles, such as suspended solids (turbidity), colloidal compounds, etc, ensuring the filtered water's TDS is less than 5. This process will reduce the load on the back-end fine filters.

2. Active Carbon filter

The active carbon filter is the key device, commonly used for the removal of organic substances and heavy metal elements, suspended solids, residual chlorine, etc. It can effectively reduce the level of COD and improve the taste of water. The system is a pressure filter. In the filter, the quartz and coconut shell active carbon beds are employed. The activated carbon is equipped with vent valves at the highest point and a drain connection at the lowest point. The internal systems and components for each tank are constructed of FRP material.

3. Sodium softener filter

Ion exchange resin is used in water softening systems for Ca+, Mg+, and other cation exchanges.

To prevent undissolved salt from depositing on the surface of the reverse osmosis membrane, the resin ensures the well-permeable ability of the membrane module after it works for a long time and extends the lifetime of membranes, enhancing the quality stability of RO-purified water. A water softener is a vertical structure that uses FRP material, produced as vessel standard, with a designed pressure of 8 kg/cm2. An American auto valve is used for full-automatic salt regeneration.

4. Security filter (micron filters)

The security filter is most commonly used for treating water. The whole system adopts one set of stainless filters. There are 3 pieces of polypropylene in every 5μ filter cartridge, filtering the vast majority of particles in the water, which eases the load of the RO membrane. This process of filtration benefits the filter cartridge and prolongs its lifetime in the system. This apparatus contains a filtration component and stainless support layers. The support layer is made of stainless steel 304, with the advantages of compact structure, beautiful shape, high flux, good filtration accuracy, etc. This apparatus is fitted with an air drain valve, a bottom air drain valve, and a side drain valve.

5. Reverse Osmosis System (RO)

The RO system is a key part of the water treatment system, which is widely used to make pure water and drinking water. RO membrane removes many types of large molecules and ions from solutions by applying pressure to the solution when it is on one side of a selective membrane. The result is that solutes such as iron, viruses, bacteria, and solids are retained on the pressurized side of the membrane, and the pure solvent is allowed to pass to the other side.

                                                            Place of Origin
                                                            CHINA

                                                            Brand Name
                                                            Qihang

                                                            Certification
                                                            CE.GMP

                                                            Model Number
                                                            RO water treatment

                                                            High Light
                                                            Shampoo Reverse Osmosis Water Treatment Equipment, Cream Reverse Osmosis Water Treatment Equipment, SS304 RO Water Treatment Equipment

                                                            Material
                                                            Stainless Steel 304/ 316L

                                                            After-sales Service Provided
                                                            Online Support

                                                            Function
                                                            Water Purification Plant

                                                            Voltage
                                                            220V / 380V

                                                            Name
                                                            RO Water Treatment Equipment
