Reverse Osmosis Water Treatment Machine

(0 reviews)

Get Price

(131) Views

(0) Contacts

Special for Cosmetics 316L Reverse Osmosis Water Treatment Machine Suspended Solids Water Purifier Systems

Contact Company

Guangzhou Qihang Machinery & Equipment Co., Ltd

Guangdong, China

(2123) Views

(7) Contacts

Reverse osmosis technology is a modern high technology recently developed in China. Reverse osmosis is the process of removing water from a solution by exerting pressure on it that is greater than the osmotic pressure once the water has passed through a particular translucent membrane. Since this process is opposite to the direction of natural penetration, it is called reverse osmosis. According to the osmotic pressure of various materials, a pressure higher than the osmotic pressure can be used for the reverse osmosis process to achieve the purpose of separation, extraction, purification, and concentration of a certain solution. It does not require heating, and there is no phase change process; therefore, it saves more energy than traditional processes.

Each link uses a different filter:

Quartz sand filter

In drinking water treatment, quartz sand filters, also known as multimedia filters, are frequently used to remove various particles, including colloidal compounds, suspended solids (turbidity), and others, in order to guarantee that the filtered water's TDS is less than 5. Reduce the burden of the back-end fine filter.

Activated carbon filter

The activated carbon filter is a key device, usually used to remove organic matter and heavy metal elements, suspended solids, residual chlorine, etc. It can effectively reduce the COD content and improve the taste of water. The system is a pressure filter. In the filter, an activated carbon bed of quartz and coconut shell is used. The activated carbon is equipped with an exhaust valve at the highest point and a discharge port at the lowest point. The internal systems and components of each storage tank are made of FRP materials.

Safety filter (micron filter)

Safety filters are most commonly used in water treatment. The whole system uses a set of stainless steel filters. There are 3 sheets of polypropylene in each 5μ filter element, which can filter most of the particles in the water, thereby reducing the load of the reverse osmosis membrane. This filtration process benefits the filter cartridge and extends its service life in the system. The device contains a filter assembly and a stainless steel support layer. The support layer is made of 304 stainless steel, which has the advantages of a compact structure, beautiful appearance, large flux, and good filtering accuracy. The device is equipped with an exhaust valve, bottom exhaust valve, and side exhaust valve.

Primary and secondary reverse osmosis system (RO)

The reverse osmosis system is a key part of the water treatment system and is widely used to produce pure water and drinking water. Many kinds of ions and macromolecules can be extracted from the solution by applying pressure when the RO membrane is on one side of the selective membrane. The result is that solutes such as iron, viruses, bacteria, and solids remain on the pressurized side of the membrane, while pure solvent can pass through the other side.

                                                            Place of Origin
                                                            China

                                                            Brand Name
                                                            QiHang

                                                            Certification
                                                            CE,ISO

                                                            Model Number
                                                            QH-RO-2

                                                            Material
                                                            Stainless Steel 304/ 316L

                                                            Warranty
                                                            1 Year

                                                            Function
                                                            Water Purification Plant,beverage Or Food Company

                                                            Type
                                                            RO Water Treatment Equipment

                                                            Operation
                                                            24 Hours Automatic Running,full Automatic Poultry Farm Waste Water Treatment

                                                            Voltage
                                                            220V / 380V

                                                            High Light
                                                            316L Reverse Osmosis Water Treatment Machine, 5.5KW Reverse Osmosis Water Treatment Machine

Reverse Osmosis Water Treatment Machine applications

1. High-quality drinking water in residential areas meets the demand for high-quality drinking water in high-end residential areas. Support drinking pure water 24 hours a day.

2. The pure water production plant can be equipped with an automatic filling machine to form an automatic barreled water production line.

3. Raw material water used in the food industry, for example, additives, ingredients, soup, or juice mixing. Pure water can improve the taste and inhibit the growth of organic matter, and increase the shelf life of the product.

4. It is recommended to use a two-stage reverse osmosis device for water production in the milk, beverage, and wine industries to prevent bad taste caused by foreign matter in the water.

5. The proportion of chemical water used in chemical raw liquid, chemical product production, chemical circulating water, etc. Pure water can effectively prevent additional chemical reactions and quality deviations caused by excessive ions in the water.

6. The boiler water used in the power industry can provide pure water for the boilers of factories, mines, coal-fired boilers, and low-pressure boiler power systems. Thereby improving production efficiency and extending equipment service life.

7. Filtration, Drinking Water, River Water, underground Water Treatment To Drinking Water, Etc
