Measurement Principle

PMI800-SS portable suspension analyzer solids analysis consists of a PMI-800 hand operator and PSS-800 suspension sensor. The SS sensor is based on a combined infrared absorption scatter ray method, and the ISO 7027 method can be used to continuously and accurately determine the suspended matter (sludge concentration). The suspended matter (sludge concentration) value was determined according to ISO 7027 infrared double scattering light technology without chromatic influence.

                                                            Measuring Range
                                                            0.1-20000 mg/L、0.1-45000 mg/L 、0.1-120000 mg/L(optional)

                                                            Model
                                                            PMI800-SS

                                                            Accuracy
                                                            Less than ±5%(homogeneity of the sludge)

                                                            Data Storage
                                                            8G

                                                            Resolution
                                                            0.1mg/L

                                                            Calibration
                                                            Standard calibration, water calibration

                                                            Display
                                                            3.5〞colorful LED, Adjustable when Backlight

                                                            Shell Material
                                                            SS sensor:SUS316L Operator:ABS+PC

                                                            Cable length
                                                            Standard: 3M(Prolong able)

                                                            Storage Temp.
                                                            1-45°C

                                                            Protective rate
                                                            Portable Host: IP66，SS sensor: IP68

                                                            Operating Temp
                                                            SS sensor size:Diam60*Length 256mm Weight:1.65KG  Portable Host:203*100*43mm(L*W*H):Weight: 0.5KG

Widely used in portable monitoring of pH/ORP in aquaculture, sewage treatment, surface water, industrial and agricultural water supply, drainage, domestic water, boiler water quality, swimming pools, scientific research universities, etc.

IP66 protection for the portable host
Ergonomic curve design with rubber washers for hand-held operation, easy to grasp in wet conditions for water testing.
Factory calibration, no calibration required in one year, can be calibrated on-site;
Easy using and fast using in the site, Digital host & plug design with the portable host.
With the USB interface, also can be charged built-in battery and exported data through the USB interface
