AG-S CONTROL TURBIDITY

(0 reviews)

Get Price

(124) Views

(0) Contacts

Contact Company

ETATRON D.S. S.P.A.

Rome, Italy

(1138) Views

(4) Contacts

The “AG S/Control” series, based on microprocessor technology, ensures a cost-effective solution for the measurement and control of turbidity. Backlit graphic display, 2 set-points for ON-OFF/Proportional interventions, 2 galvanic separate programmable 4-20 mA outputs, maximum dosing alarm, relay output alarm, and relay output for probes cleaning.

                                                            Measure
                                                            NTU

                                                            Range
                                                            0…20,00 NTU (±0.01 NTU) 0…200,0 NTU (±0.1 NTU)

                                                            Power supply
                                                            100 ÷ 240 Vac – 50 Hz

                                                            Box
                                                            ABV, IP65 protection degree

                                                            Display
                                                            Graphic backlighted

                                                            Temperature sensor
                                                            automatic/manual compensation 0-100°C (NTC)

                                                            Input
                                                            Level and flow sensor

                                                            Set point
                                                            n° 2 relay output free contact, max 5A

                                                            Parameters
                                                            range, hysteresis, delay, High/Low alarm

                                                            Working mode
                                                            ON/OFF or time proportional

                                                            Datalogger
                                                            Internal

                                                            Output alarm
                                                            1 Relay fre contact (5 A max)

                                                            Output mA
                                                            n° 1 output 4÷20 mA, proportional and programmable with galvanic separation n° 1 output 4÷20 mA, (recorder) with galvanic separation (400 Ohm)

                                                            Data control (optional)
                                                            serial output RS232 for remote control (via software)

                                                            Output TTL
                                                            n° 1 pulse output adjustable
