Threaded Ultrasonic Water Meter

(0 reviews)

Get Price

(64) Views

(0) Contacts

Contact Company

WESDOM

Henan, China

(265) Views

(3) Contacts

Description of Ultrasonic Water Meter
Ultrasonic water meter is a new type of water meter that detects the time difference caused by the change of velocity when the ultrasonic beam propagates in the opposite direction of the water and analyzes and processes the flow rate of water to further calculate the flowing of water.

Compositions of Ultrasonic Water Meter
It is composed of the flow sensor, calculators, pipe fittings, etc., detailed as follows.
Notices for Installation of Ultrasonic Water Meter

Flush pipes before installation to avoid gravel and other foreign objects
Install a valve and filter before the water meter
Please note that the arrow direction on the pipe shall be consistent with the water flow direction during installation
The water meter shall not be installed at a place that may be affected by strong mechanical vibrations
Do not touch the electrical part or pull wires to avoid damage during installation
When the water meter is installed in a horizontal or inclined way, the ultrasonic flow probe on pipes shall be placed horizontally, and when installed in a vertical way, make
sure the water flows from down to up
The joint washer shall be installed correctly to avoid misaligned washer blocking water and affecting the accuracy of the water meter
Contacts
Before using this water meter, the pipe must be filled with water, otherwise, it will lead to inaccurate or even non-measurement
Product parameter
Please make sure the medium flow is within the flow range of the water meter during test and use, otherwise, it may result in damage to the water meter
In case of any malfunction (e.g. metering failed etc.) during use, please contact the related management department immediately and do not repair it by yourself
The product is designed with a disposable anti-disassembly seal which shall be removed only by appointed personnel, or otherwise, it shall be excluded from the free after-sales service

                                                            Temperature range
                                                            Q3/01, R200/ (R250 customizable)

                                                            Accuracy class
                                                            Class B

                                                            Working pressure
                                                            1.6 MPa

                                                            Temperature range
                                                            (5-55) C
