Good Quality Aeration Tube Diffuser Made in China

Featured

Good Quality Aeration Tube Diffuser Made in China

(0 reviews)

Get Price

(3454) Views

(0) Contacts

1 - 99 sets
$10.00
100 - 999 sets
$9.80
>= 1000 sets
$9.00

Contact Company

Hangzhou Juntai Plastic Products Co., Ltd

Hangzhou, China

(4051) Views

(91) Contacts

Maintenance-free design, 8 years of service life
EPDM/SILICONE membrane with excellent performance
Juntai Smart Tube Diffuser Installation
1. Good quality aeration tube diffuser made in China can be used in a variety of water aeration, and oxygenation applications. Our Good quality aeration tube diffuser made in China is designed with a 3/4 FPT connection but comes with an MPT nipple for easy conversion if desired.
2. This nipple also allows users to install our Tube Diffusers using the same Universal Diffuser Mount mentioned above. Simply tap a 1 hole in your piping system and screw in the tube with the attached MPT nipple.
3. Again once all of the diffusers are installed, fill the area just above the diffuser line with water and check for any faulty installations and/or Leaks.
Why choose the Juntai Smart Tube Diffuser:
1. Successful long-term use in innumerable installations worldwide
2. Simple installation and low level of investment
3. High oxygen transfer –confirmed in numerous tests at accredited institutes
4. Optimum adjustment to tank form and diffuser depth
5. Best possible design –considering diffuser density, airflow, and oxygen transfer– due to many years of experience

Item number	TD63	TD93	TD113
Bubble type	Fine Bubble	Fine Bubble	Fine Bubble
Tube diameter(mm)	63	93	112
Material	Special Formula EPDM with UV Protector import from Germany
Material	Tube material: Acrylonitrile-butadiene-styrene with UV Protector (ABS)
Length	500/750/1000mm	500/750/1000mm	500/750/1000mm
Connector	3/4NPT	3/4NPT	3/4NPT
Flow range(m³/h)	2-14	5-20	6-28
Bubble Size(mm)	1-2	1-2	1-2
Service Area(m²)	0.75-2.5	1.0-3.0	1.5-2.5

                                                            Model
                                                            TD63,TD96,TD113

                                                            Moc
                                                            Special formula EPDM

                                                            Tube
                                                            reinforced ABS(Acrylonitrile Butadiene Styrene)with UV Protector

                                                            Diameter
                                                            93mm

                                                            Length
                                                            750mm and other length

                                                            Connector
                                                            3/4NPT

                                                            Flow range（m³/h)
                                                            5-20

                                                            Bubble size(mm)
                                                            1-2

1. Preservation aeration of wastewater
2. Oxygenation of activation basins
3. Oxygenation to stabilize sludge
4. Aeration of rivers and lakes
5. Aeration of fish ponds
6.CO2 admission for neutralization
