Analogue Solenoid Dosing Pump

(0 reviews)

Get Price

(164) Views

(0) Contacts

Compact Solenoid dosing pump with configurable foot or wall mount bracket

Contact Company

ETATRON D.S. S.P.A.

Rome, Italy

(1136) Views

(4) Contacts

PVDF-FPM Standard Kit
ALL DLX is supplied with a standard PVDF-FPM installation kit, made up of a 2m discharge PE tube (4x6mm), 2m suction + 2m bleeding PVC crystal tube (4x6mm), PVDF foot-filter, PVDF injection valve. Other configurations are available upon request.

Model PKX MA/A

• Manual flow rate adjustment from 0 – 100%
• Flow rate up to 7 L/H
• Operating pressure up to 7 bar
• Max stroke rate: 120 impulses/min
• Manual air bleed pump head
• Level probe input PKX MA/AL model only
• IP65 protection degree
• Wall or foot mounting plastic bracket (included)
• STD Power Supply: 230 Vac 50-60 Hz
• Optional power supply: 120 Vac 50-60 Hz / 12Vdc / 24Vac-Vdc
• Flashing LED under working conditions
• PP reinforced housing
• PP pump head with Lip valves
• Pump head options include PVDF with ceramic balls; Auto-bleed
• PE diaphragm
• Available with removable power cable
• Extra silent version available upon request
• Supplied with PP Complete Installation Kit
