BT MA/M Heavy duty wall mounted Digital Solenoid Dosing Pump

(0 reviews)

Get Price

(158) Views

(0) Contacts

Contact Company

ETATRON D.S. S.P.A.

Rome, Italy

(1170) Views

(4) Contacts

The BT range is designed for larger Flow Rates (Up to 80 L/H).

PVDF-FPM Standard Kit
ALL BT are supplied with a standard PVDF-FPM installation kit: PE discharge tube, PVC suction tube, PVDF foot-filter, and PVDF injection valve.

• Flow rate up to 80 l/h
• Operating pressure up to 20 bar
• Standard pump head: PP or PVDF body, PTFE diaphragm, ceramic balls, FPM sealings*
• 30 – 80 l/h pumps are supplied with PVC pump heads and accessories with fittings for 10×14 tubing
• The casing is in aluminum protected with two coats of epoxy paint
• Manual air bleed pump head; from 5 to 15l/h automatic air bleed available on request
• Control panel protection is assured by a transparent polycarbonate cover with a gasket
• Level probe input
• IP65 protection degree
• Wall mounted
• Power Supply: 230 Vac 50-60 Hz
• On-request power supply: 240 Vac 50-60 Hz; 110 Vac 50-60 Hz
• Strokes frequency: 160 impulses/minute maximum (5-20 L/H models only) - 180 impulses/minute maximum (30-80 L/H models only)
• CE (standard) and CSA certified (on request)
• Digital control
• Display: 7 segments
• Manual flow rate adjustment 0÷100%
