The BT range is designed for larger Flow Rates (Up to 80 L/H)
PVDF-FPM Standard Kit
ALL BT are supplied with a standard PVDF-FPM installation kit: PE discharge tube, PVC suction tube, PVDF foot-filter, PVDF injection valve

Model BT PH-RX-CL/M

• Flow rate up to 80 l/h
• Operating pressure up to 20 bar
• Standard pump head: PP or PVDF body, PTFE diaphragm, ceramic balls, FPM sealings*
• 30 – 80 l/h pumps are supplied with PVC pump heads and accessories with fittings for 10×14 tubing
• The casing is in aluminum protected with two coats of epoxy paint
• Manual air bleed pump head; from 5 to 15l/h automatic air bleed available on request
• Control panel protection is assured by a transparent polycarbonate cover with a gasket
• Level probe input
• IP65 protection degree
• Wall mounted
• Power Supply: 230 Vac 50-60 Hz
• On-request power supply: 240 Vac 50-60 Hz; 110 Vac 50-60 Hz
• Strokes frequency: 160 impulses/minute maximum (5-20 L/H models only) - 180 impulses/minute maximum (30-80 L/H models only)
• CE (standard) and CSA certified (on request)
• Digital manual flow rate adjustment 0÷100%
• Proportional dosing modes: 0.00 – 14 pH; -1000/+1400 mV Redox; 0-2 / 0-20 / 0-200 ppm
• ON/OFF or proportional mode
• Daily and weekly timer (8 programs/day)
• Output 4-20mA
• Relay Output
• Pt100 probe 0÷100°C
• Proximity switch
• Alarm: Max – Min – Over
• Hysteresis
• Direct or Reverse Intervention
• Display: backlighted
