Flange Adaptor

(0 reviews)

Get Price

(212) Views

(0) Contacts

universal flange adaptor

Contact Company

Saudi Pipe Systems Company (SPS co.)

Jeddah, Saudi Arabia

(1341) Views

(27) Contacts

An SPS universal flange adaptor can be used to connect various outer diameters of UPVC, steel, cast iron, GRP, and ductile iron. Drilling specifications for flanges are ANSI B16.5, DIN 2501 PN10/PN16/PN25, and BS 4504 PN10 & PN16. Quick and simple installation.
Rubber gaskets are ribbed to seal damaged and rusted pipe and provide positive compression. Protection against corrosion using fusion-bonded epoxy with a minimum of 250 microns. An angular deviation of 3º is permitted on all sides with the SPS Universal Flange adaptor. 16 bar (230 PSI) of working pressure.

specifics
1. Ductile iron GGG50 to DIN EN 1563 flange
2. Ductile iron rings, DIN EN 1563 to GGG50
3. Type-G rubber gasket (1990); Grade-G nitrile compound to BS 2494
4. G.I. BS 970 Bolts and Nuts, 1991 Grade 070 M20

5. G.I. BS 729; 1971; Bolt coating

6. Coating: 250 micron fusion-bonded epoxy
