The Mini Circuit Breaker (MCB) is an electrical protection device that can be used to protect electrical circuits and equipment against overloads and short circuits. This small and efficient breaker has a wide range of applications, making it an indispensable component in residential, commercial, and industrial electrical systems.

                                                            Rated Current  A
                                                            1, 2, 3, 4, 5, 6, 10, 16, 20, 25, 32, 40, 50, 63

                                                            Storage Temperature  ℃
                                                            -25 - +70

                                                            Number Of Poles  P
                                                            1P, 2P, 3P, 4P

                                                            Rated Voltage  V
                                                            1P: 240/415V; 2P, 3P, 4P: 415V

                                                            Protection Degree
                                                            IP20

                                                            Rated Frequency  Hz
                                                            50/60

                                                            Mechanical Life  t
                                                            ≥20000 operations

                                                            Rated Breaking Capacity  A
                                                            4500 6000

                                                            Electrical Life  t
                                                            ≥6000 operations

                                                            Rated Impulse Withstand Voltage (1.2/50) Up  V
                                                            4000

                                                            Thermo-magnetic Release Characteristic Curve
                                                            B, C, D

                                                            Model
                                                            CTN1-63

Submission of Applications:
Residential:
In houses, MCBs are widely employed to protect lighting circuits, appliances, and power outlets.
They are found in factories, warehouses, and production lines.
They are required in kitchens, baths, and bedrooms where a high level of security is required.
Commercial:
MCBs protect office equipment, HVAC systems, and lights in business settings.
They are great for retail, workplace, and restaurant settings.
Industrial:
MCBs serve an important function in the protection of machinery and equipment in industrial facilities.
They are found in factories, warehouses, and production lines.
Energy from Renewable Resources:
MCBs are used to protect inverters, batteries, and other components in solar and wind energy projects.
They ensure that renewable energy systems operate safely and efficiently.
Telecommunications:
Critical infrastructure in telecommunications networks is protected by MCBs.
They're found in data centers, telecommunications towers, and communication hubs.
Transportation:
MCBs are used to protect electrical systems onboard trains, buses, and ships, among other types of transportation.
They ensure the security and dependability of transportation systems.
Conclusion:
The Mini Circuit Breaker is a versatile and small electrical protection device that can be used in a variety of applications. Whether you need to secure your house, company, or industrial building, our MCBs provide dependable and effective electrical fault protection. You can rely on our knowledge and quality to maintain your electrical systems safe and operational.

Features include
Small Size:
One of the Mini Circuit Breaker's notable features is its small size. It is designed to fit into narrow gaps within electrical distribution panels, making it perfect for tight-fitting installations.
Mechanism for Tripping:
The MCB is equipped with a dependable tripping mechanism that responds quickly to overcurrents and short circuits. This guarantees that the connection is quickly disconnected, preventing harm to linked equipment and wires.
Ratings as of now:
Our MCBs are available in a range of current ratings, from 1A to 63A, to suit a wide range of applications. There is an MCB for any application, whether it is to protect a sensitive electronic circuit or a heavy-duty industrial equipment.
Sensitivity can be adjusted:
Some of our Mini Circuit Breakers include changeable sensitivity levels, allowing you to fine-tune the level of protection based on your application's individual needs.
Dependable Performance:
Our MCBs are built to last, using high-quality components and stringent quality control techniques. They provide great performance even in severe settings, extending the life of your electrical system.
Curve of Characteristics
Thermo-magnetic Expansion Characteristic MCB curves often have B, C, and D curves.
The B Curve indicates that the MCB trips between 3 and 5 times the total load current. It is mostly utilized in residential applications with resistive loads, including as lighting fixtures and domestic appliances with modest surge levels.
The C Curve indicates that the circuit breaker trips 5-10 times the full load current.
The D Curve indicates that the MCB trips between 10 and 14 times the overall load.
