TM-11A Temperature Sensors

(0 reviews)

Get Price

(69) Views

(0) Contacts

Contact Company

Changzhou KB Instrument & Meter Co., Ltd.

Jiangsu, China

(757) Views

(0) Contacts

                                                            Material
                                                            Head: Aluminum Pocket: stainless steel

                                                            Sensor element
                                                            1xPt100 3-wire/class B 1xPt1000 2-wire/class B

                                                            Electric connection
                                                            Head form B with ceramic socket (BO) Head form B with transmitter (BT)

                                                            Protection
                                                            IP54

                                                            Immersion Tube length
                                                            100mm, 120mm, 150mm......300mm

                                                            Tube diam
                                                            10mm or 12mm

                                                            Temperature
                                                            Resistance: 0+200C Thermocoupls: 0...600C .0+1200C

                                                            Accuracy class
                                                            Resistance thermometer class B Thermocouple class 1

                                                            Process connection
                                                            Fix connection thread

Applications of Temperature Sensors
For measuring the temperature difference between two points by pairs of dissimilar metal wires, and used in many appliances like indicators and controllers.
