Installation
Installed in the matching flow cell, the electrode and the flow cell are installed tightly, ensuring that the electrode measurement part is placed near the inlet of the circulation slot. Area, try not to face the water outlet to ensure a smooth flow rate. It is recommended to control the flow rate at 30-60L/h to ensure the accuracy of the test

                                                            Model
                                                            DS260

                                                            Principle
                                                            Constant  voltage method

                                                            Response time
                                                            ＜30s

                                                            Protection level
                                                            IP68

                                                            Measuring range
                                                            0~40.00mg/L (HClO)

                                                            Resolution
                                                            0.001mg/L

                                                            Accuracy
                                                            2% or 0.01mg/L

                                                            Flow rate
                                                            30~60L/h

                                                            Calibration
                                                            Two-point calibration (zero point and slope)

                                                            Size
                                                            Φ30*233 mm

                                                            Temperature
                                                            Automatic temperature compensation (digital temperature

                                                            Power supply
                                                            DC 12~24V, current <50mA

                                                            Output Support
                                                            RS-485, MODBUS protocol

                                                            Installation
                                                            Circulation slot

                                                            Material
                                                            Polyacetal resin, polytetrafluoroethylene, gold, silver,

                                                            Temperature range
                                                            0~50°C

For drinking water treatment plants, canning plants, drinking water distribution networks, swimming pools, cooling circulating water, water treatment projects, etc. The case where the residual chlorine content in the aqueous solution is continuously monitored
