Centrifuge Separator

(0 reviews)

2500 USD

(244) Views

(0) Contacts

>= 1 pieces
$2,500.00

Contact Company

Wuxi Ewater Water Treatment Co., Ltd.

Jiangsu, China

(2047) Views

(32) Contacts

The key equipment of the sludge dewatering system is the sludge dewatering host, that is, the horizontal spiral discharge sedimentation centrifuge (abbreviated as decanter centrifuge), which uses the principle of centrifugal sedimentation to separate suspended solids.
For various suspensions with solid particle equivalent diameter ≥ 3um, weight concentration ratio ≤ 10% or volume concentration ratio ≤ 70%, liquid-solid density difference) 0.05g/cm3, this type of centrifuge is suitable for liquid-solid separation.

Working principle

The drum and the screw rotate at a high speed in the same direction at a certain differential speed.
The material is continuously introduced into the inner cylinder of the conveying screw from the feed pipe and then enters the drum after being accelerated.
Under the action of the centrifugal force field, the heavier solids are deposited on the wall of the drum.
A layer of sediment is formed. The conveying screw continuously pushes the deposited solid phase to the cone end of the rotating drum and discharges it out of the machine through the slag discharge port.
The lighter liquid phase forms an inner liquid ring, which continuously overflows the drum from the overflow port at the large end of the drum, and is discharged out of the machine through the liquid discharge port.
This machine can continuously feed, separate, wash, and discharge materials at full speed.

Advantages
1. Good adaptability: In the process, the various special requirements of materials and processes on the centrifuge are fully considered, and the main components are optimized in terms of specificity and adjustability. As long as the user explains the place where it is installed and used, the physical and chemical characteristics of material handling, and the process requirements before purchasing the machine, we will provide the user with a suitable model.
2. High degree of automation: the feeding, separation, unloading, and other processes of the centrifuge are continuously and automatically carried out under high-speed operation. A programmable controller is used to realize automatic control of the centrifugal separation and centrifugal washing process.
3. Good operating stability: The differential used in the centrifuge is a cycloid differential or a planetary differential, which has the characteristics of large torque and a wide adjustment range.
4. Strong craftsmanship: The centrifuge adopts dual-motor dual-frequency energy feedback differential speed system control, which makes flexible and stepless adjustments to the differential speed, and adjusts the differential speed at any time according to the changes of materials. A real energy-saving product.
5. Good operating environment: The separation of materials by the centrifuge is carried out under completely airtight conditions to ensure that the operation site is clean and pollution-free, and the production environment is clean and hygienic to realize civilized production.
6. The safety protection device is complete and reliable: the centrifuge is equipped with multiple protections such as torque protection and power control, which can effectively eliminate or reduce the damage to the machine caused by sudden failure.
7. Beautiful appearance: The base of this machine is welded with high-quality carbon steel, and the surface is treated with special technology to make it smooth and flat. Lightweight, generous, and beautiful, giving people a sense of overall beauty.

                                                            Warranty of core components
                                                            1 Year

                                                            Capacity
                                                            0.5-18m3/H

                                                            Core Components
                                                            Motor

                                                            Type
                                                            Horizontal spiral

                                                            Place of Origin
                                                            Jiangsu, China

                                                            Brand Name
                                                            Ewater

                                                            Material
                                                            Carton

                                                            Weight
                                                            100, 1000KG

                                                            Power
                                                            0.75

                                                            Warranty
                                                            1 year

                                                            Productivity
                                                            500L/Hour

                                                            Weight (KG)
                                                            100 kg
