Electrodeionization - EDI Modules for Water Polishing

(0 reviews)

(297) Views

(0) Contacts

Electro De-Ionization is currently the most advanced technology for ion-exchange. With this technology (ultra)pure water can be produced continuously.

1 - 4 sets

$330.00

5 - 19 sets

$315.00

>= 20 sets

$288.00

Contact Company

Fujian Huamo Technology Co., Ltd.

Fujian, China

(1416) Views

(41) Contacts

Electrodeionization (EDI) is an electrically-driven water treatment technology that uses electricity, ion exchange membranes and resin to remove ionized species from water.<br
It is wisely combined electro dialysis with ion exchange technology, by using of high-voltage electrodes at both ends to drive charged ion in the water to move, and with the ion exchange resin and selective resin membrane to accelerate ions moving, so as to achieve the purpose of water purification.

Requested Of Feed Water:

Resource water: RO water conductivity less than 20 us.cm better than 10 us.cm
PH: 6.0-9.0
Temperature: 5-35’c
Hardness: Less than 0.5ppm
Organics: Max 0.5ppm, Recommend 0 ppm
Oxidizers: Max 0.05ppm
FE MN: Max 0.01ppm
Silica: Max 0.5ppm
Carbon Dioxide: max 5ppm
Oil: Not Detectable

This high-end technology can have an application in sectors such as: Power plants, process industry and pharmaceutical industry. An EDI-unit is usually used as a post treatment of Reverse Osmosis water.
